| Rated Output | 额定输出 | 1.0mV/V ±1% |
| Zero Balance | 零点平衡 | ±1% of rated output |
| Creep after 30 minutes | 蠕变 | ±0.2% of rated output |
| Nonlinearity | 非线性 | ±0.5% of rated output |
| Hysteresis | 滞后 | ±0.5% of rated output |
| Repeatability | 重复性 | ±0.5% of rated output |
| Temp. effect on output | 灵敏度温漂 | ≤0.02% of applied output/ºC |
| Temp. effect on zero | 零点温漂 | ≤0.02% of rated output/ºC |
| Safe Temp. Range | 可用温度范围 | -10ºC to + 70ºC |
| Temp. Compensated | 温度补偿范围 | -10ºC to + 40ºC |
| Safe Overload | 安全载荷 | 150% |
| Ultimate Overload | 极限载荷 | 200% |
| Input Impedance | 输入阻抗 | 775 ohm ± 20 ohm |
| Output Impedance | 输出阻抗 | 700 ohm ± 5 ohm |
| Insulation Resistance | 绝缘阻抗 | ≥5000 M ohm (50V DC) |
| Rated Excitation | 推荐激励电压 | 10V DC/AC |
| Maximum Excitation | 最大激励电压 | 15V DC/AC |
| Cable Length | 导线长度 | 6m |
| Cable Color Code | 导线颜色 | Red(+E) Black(-E) Green(+S) White(-S) |
